| Manyleb | Pellter y ganolfan -500Umm | Pellter y ganolfan-1000Umm | |
|---|---|---|---|
| Gallu Gweithio | Diamedr swing Max | 695mm | 728mm |
| Diamedr gweithio Max | 340mm | 340mm | |
| Capasiti prosesu Max Bar (Dylanwad gan chuck) | 65mm | 65mm | |
| Hyd gweithio uchaf | 535mm | 1085mm | |
| Prif Echel | chuck Maint | 8in | 8in |
| Cyflymder cylchdroi Max | 5000rpm | 5000rpm | |
| Pwer modur (sgôr 30 munud) | 15kw /20.0hp | 15kw /20.0hp | |
| Twr Cyllell | Torri meintiau offer | 12 | 12 |
| Cyflymder cylchdroi Max | 4500rpm | 4500rpm | |
| Pwer modur (sgôr 30 munud)) | 5kw /7.5hp | 5kw /7.5hp | |
| Siafft porthiant | Traval Effeithiol (echel X) | 215mm | 215mm |
| Traval Effeithiol (echel Y) | 100mm | 100mm | |
| Traval Effeithiol (echel Z) | 605mm | 1155mm | |
Canolfan droi Yamazaki Mazak QT-Compact 200MY pellter pellter -1000umm canolfan prosesu
Y diamedr troi uchaf yw 728 mm
Y diamedr peiriannu uchaf yw 340 mm
Uchafswm capasiti prosesu bar (wedi'i effeithio gan chuck) 65 mm
Yr hyd prosesu uchaf yw 1085 mm
